Description

Overview

Streamlined and straightforward, our new Elite range offers essential features and premium components to deliver high output and exceptional sound quality for professional users.

The EL15P is a full-range powered speaker with a 15” neodymium woofer that delivers 2500 watts of peak power (1250 watts program).

The rugged cabinet is constructed from high-quality birch and features a pole mount adapter and integrated flypoints. An optional
bracket is available separately for multi-cabinet hangs.

The rear panel features an XLR / 1/4” input jack, XLR output, and powerCON® TRUE1 connector.

 Features

• 2500 W Peak Power (1250 W Program)
• 15” Neodymium Woofer with 3” Voice Coil
• ABS Horn with Neodymium Magnet and 1.4” Exit
• Onboard Limiter
• powerCON ® TRUE1 Input
• 15 mm Birch Plywood Construction
• Made in Canada

Specifications

Power Rating:                           2500 W Peak                                                                                                                                                         1250 W Program

Max SPL:                                 139 dB Peak (127 dB Continuous)

Frequency Response:              50 Hz – 20 kHz (+/- 3 dB)

Crossover Frequency:              850 HzLF

HF Driver(s):                             ABS Horn with 1.4” exit, 3” Voice Coil                                                                                                                    and Neodymium Magnet

HF Dispersion (H x V):             60° x 40°

HF Horn:                                  Injection-Molded ABS

Level Controls:                         Yes

Inputs:                                       1x XLR / TRS

Outputs:                                    1x XLR

Flypoints:                                  4x Top, 4x Bottom, 2x Pull Back

Optional Flying Hardware:        EL15PBRACKET                                                                                                                                          2-3 Cabinet Array Bracket                                                                                                                                      (Sold Separately)

Bar Handles:                             2x Side

Pole Mount Adapter:                 1x Bottom

Enclosure Materials:                 ABS-Coated Birch Plywood

Cabinet Finish:                          Textured Paint

Grille:                                         Powder-Coated Steel

Power Cable:                             powerCON® TRUE1 Connectors

Power Consumption(Typ / Max): 3A, 7.5A
